Parameter Address
Default Min Max Unit Logic Diagram
Overload recording
OL_RC: No. overload
004 101
0 0 9999 Fig. 3-68, (p. 3-98)
[spacer]
Number of overload events.
Parameter Address
Default Min Max Unit Logic Diagram
Fault recording
FT_RC: No. of faults
004 020
0 0 9999 Fig. 3-74, (p. 3-105)
[spacer]
Number of faults.
[spacer]
FT_RC: No. system disturb.
004 010
0 0 9999 Fig. 3-74, (p. 3-105)
[spacer]
Number of system disturbances.
Parameter Address
Default Min Max Unit Logic Diagram
Definite-time over‐
current protection
DTOC1: No. general start.
009 150
0: don't execute Fig. 3-96, (p. 3-130)
[spacer]
Number of general starting signals.
Parameter Address
Default Min Max Unit Logic Diagram
Definite-time over‐
current protection
DTOC2: No. general start.
009 160
0: don't execute
[spacer]
Number of general starting signals.
Parameter Address
Default Min Max Unit Logic Diagram
Inverse-time overcur‐
rent protection
IDMT1: No. general start.
009 151
0: don't execute Fig. 3-108, (p. 3-144)
[spacer]
Number of general starting signals.
