Parameter
Destination
Parameters
Evaluation Expression
Criteria to check the received information content by comparing it with a set
integer value; the parameter is not supported in the device.
●
Equal to (Compared to: equal)
●
Not equal to (Compared to: unequal)
●
Greater than (Compared to: greater)
●
Less than (Compared to: less)
●
Pass through (Do not compare)
Default Input Value
Default value for the information in case GOOSE receipt has failed.
●
False – not set
●
True – set
●
Last Known Value – retain last value received
●
Double Point: intermediate (00) – switching device in intermediate position
●
Double Point: Off (01) – switching device open
●
Double Point: On (10) – switching device closed
●
Double Point: Bad state (11) – switching device in intermediate position
Invalidity Quality bits
Quality criterion, which is to be tested.
●
Invalid / Questionable: Invalid / questionable
●
Source: Information source is faulty
●
Relay test: Sending device is set to test mode
●
OperatorBlocked: Blocked by operator
and
●
Overflow: Measured value has exceeded its capacity
●
OutofRange: Measured value has exceeded its range
●
BadReference: Referenced value is faulty
●
Oscillatory: Value is volatile
●
Failure: Faulty
●
OldData: Information is out-of-date
●
Inconsistent: Information is unreliable
●
Inaccurate: Information is inaccurate
9 IEC 61850 Settings via IED Configurator
