A4.1.1.2 Physical Layer (Network-Specific Parameters)
(See National Preface of EN 60870-5-101.)
Transmission Rate (Control Direction)
(The transmission rates for control direction and monitor direction must be
identical.)
Unbalanced interface V.24/V.28,
Standardized
Unbalanced interface V.24/V.28,
Recommended with > 1 200 bit/s
Balanced interface X.24/X.27
[ ] 100 bit/s [✓] 2400 bit/s [ ] 2400 bit/s
[ ] 200 bit/s [✓] 4800 bit/s [ ] 4800 bit/s
[ ] 300 bit/s [✓] 9600 bit/s [ ] 9600 bit/s
[✓] 600 bit/s [ ] 19200 bit/s
[✓] 1200 bit/s [ ] 38400 bit/s
[ ] 56000 bit/s
[ ] 64000 bit/s
Transmission Rate (Monitor Direction)
(The transmission rates for control direction and monitor direction must be
identical.)
Unbalanced interface V.24/V.28,
Standardized
Unbalanced interface V.24/V.28,
Recommended with > 1 200 bit/s
Balanced interface X.24/X.27
[ ] 100 bit/s [✓] 2400 bit/s [ ] 2400 bit/s
[ ] 200 bit/s [✓] 4800 bit/s [ ] 4800 bit/s
[ ] 300 bit/s [✓] 9600 bit/s [ ] 9600 bit/s
[✓] 600 bit/s [ ] 19200 bit/s
[✓] 1200 bit/s [ ] 38400 bit/s
[ ] 56000 bit/s
[ ] 64000 bit/s
