Version Changes
F_KEY The new detachable control panel (HMI) is fitted with 6
freely configurable function keys which may be used
either as switches or keys, and are password protected.
Because of this the function group F_KEY “Configurable
Function Keys” has been added.
CBF_x Implementation of the new circuit breaker failure
protection function including a current reset criterion.
The number of availabe function groups corresponds to
the number of transformer ends, that is for the P631, 2
function groups are available.
LOC Because of the ordering option “detachable HMI” this
additional Device Identification parameter is now
available: LOC: Local HMI exists (221 099).
P631
‑306/307
‑405/406
‑611-715
Release: 2007-06-12
Hardware
No changes.
Diagram
No changes.
Software
LOC
Bug fixing:
●
Reset functions configured to the CLEAR key ('C')
are now carried out correctly.
A system restart could previously occur when the
detachable HMI was disconnected.
CBF_x Timer stages ‘t1 3p’ and ‘t2’ of function CBF_2 are now
processed regardless of the setting at CBF_1.
IEC The ICD files have been modified. urcbMX has been
added to the logical nodes PhsPDIF1, Rf1PDIF1,
Rf2PDIF1 and Rf3PDIF2. Implementation of the
communication protocol IEC 61850 in these versions is
KEMA certified.
P631
‑306/307
‑405/406
‑611-716
Release: 2007-08-31
Hardware
No changes.
Diagram
No changes.
Software
A5 P631 Version History
P631
P631/EN M/R-11-C // P631-310-650 A5-13
