Page 42
Measure
optoCONTROL 2600
Hexcode Name Interpretation
0x00002001 RESET Reset and reboot
0x00002011 INFO Information command
(indicates sensor data)
0x00002021 STOP Terminate measurement output
0x00002022 START Permanent measurement
output
0x00012023 CHOOSE MP Change the current measure-
ment program
0x00022024 SWITCH EDGE Change the edges to be mea-
sured in the segment measure-
ment program
0x00002025 RD OPT RAM Read the option data to the
main memory
0x00002026 RD MPR RAM Read the measurement
program data from the main
memory
0x000B2027 WR OPT TO RAM Write the option data to the
main memory
0x000F2028 WR MPR TO RAM Write the measurement pro-
gram data to the main memory
0x00002029 SAVE OPT RAM TO FLASH Save the option data from
the main memory to the flash
memory
0x0000202A SAVE MPR RAM TO FLASH Save the measurement pro-
gram data from the main mem-
ory to the flash memory
0x0000202B TRIGGERMODE RESET In the measurement mode
“Trigger mode”: reset active,
reset of the output values
0x0000202C TRIGGERMODE TRIGGER In the measurement mode
“Triggermode”: trigger active,
activate output
0x0000202D SET_LIGHT_REFERENCE_TUNING Activates the light reference
tuning, detection of a flexible
threshold value for dark/light
transition
0x0000202E RESET_LIGHT_REFERENCE_TUNING Activates a fixed threshold val-
ue for dark/light transition
0x00002033 RD MINMAX Read out the min/max values
0x00002034 RD MINMAX RESET Read out the min/max values
with reset
Fig. 48 Overview of the optoCONTROL 2600 commands
