MICRO-EPSILON optoCONTROL 2600 User Manual

Page 55
Measure
optoCONTROL 2600
6.6.3.16 Activating the Output in the Trigger Measurement Mode
Name
TRIGGERMODE TRIGGER
Description: Activates the output in the trigger measurement mode
Command:
Byte 1 Byte 2 Byte 3 Byte 4 hex
„+“ „+“ „+“ 0x0D 0x0D2B2B2B
„0“ „D“ „C“ „1“ 0x3143444F
0x2C 0x20 0x00 0x00 0x0000202C
i
This command corresponds to the external trigger input in the trigger measurement
mode.
Response:
Byte 1 Byte 2 Byte 3 Byte 4 hex Remark
„0“ „D“ „C“ „1“ 0x3143444F
0x2C 0xA0 0x03 0x00 0x0003A02C Without error
0x00 0x00 0x00 0x00 0x00000000 Error code
6.6.3.17 Activating the Light Reference Tuning
Name
SET LIGHT REFERENCE TUNING
Description: Activates the output in the trigger measurement mode.
Command:
Byte 1 Byte 2 Byte 3 Byte 4 hex
„+“ „+“ „+“ 0x0D 0x0D2B2B2B
„0“ „D“ „C“ „1“ 0x3143444F
0x2D 0x20 0x00 0x00 0x0000202D
i
This command corresponds to the menu „1B20 - Light reference tuning“.
Response:
Byte 1 Byte 2 Byte 3 Byte 4 hex Remark
„0“ „D“ „C“ „1“ 0x3143444F
0x2D 0xA0 0x03 0x00 0x0003A02D Without error
0x00 0x00 0x00 0x00 0x00000000 Error code
Possible errors:
0x0000000D Unsuccessful Light reference tuning, optical path not free
