Page 54
Measure
optoCONTROL 2600
Response:
Byte 1 Byte 2 Byte 3 Byte 4 hex Remark
„0“ „D“ „C“ „1“ 0x3143444F
0x28 0xA0 0x03 0x00 0x0003A028 Without error
0x00 0x00 0x00 0x00 0x00000000 Error code
Avoid error!
> Data are not accepted!
Possible errors:
0x00000004 Too much data received
0x0000000A Error on writing to the RAM
0x0000000B Incorrect data transmitted, see Valid values
6.6.3.14 Save Measurement Program Data
Name
SAVE MPR RAM TO FLASH
Description: With this command the currently valid measurement program data
is written from the main memory to the flash memory.
Command:
Byte 1 Byte 2 Byte 3 Byte 4 hex
„+“ „+“ „+“ 0x0D 0x0D2B2B2B
„0“ „D“ „C“ „1“ 0x3143444F
0x2A 0x20 0x00 0x00 0x0000202A
Response:
Byte 1 Byte 2 Byte 3 Byte 4 hex Remark
„0“ „D“ „C“ „1“ 0x3143444F
0x2A 0xA0 0x03 0x00 0x0003A02A Without error
0x00 0x00 0x00 0x00 0x00000000 Error code
Possible errors:
0x00000006 Flash - access error
6.6.3.15 Resetting the Output Values in the Trigger Measurement Mode
Name
TRIGGERMODE RESET
Description: Resets the output values in the Trigger measurement mode
Command:
Byte 1 Byte 2 Byte 3 Byte 4 hex
„+“ „+“ „+“ 0x0D 0x0D2B2B2B
„0“ „D“ „C“ „1“ 0x3143444F
0x2B 0x20 0x00 0x00 0x0000202B
i
This command corresponds to the external reset input in the Trigger measurement
mode.
Response:
Byte 1 Byte 2 Byte 3 Byte 4 hex Remark
„0“ „D“ „C“ „1“ 0x3143444F
0x2B 0xA0 0x03 0x00 0x0003A02B Without error
0x00 0x00 0x00 0x00 0x00000000 Error code
