Measure
optoCONTROL 2600
Median Binary
unsigned
short
16 0, 3, 5, 7, 9 0 ... no Median
3, 5, 7, 9 Median
over n values
Average Binary
unsigned
short
16 1 ... 4096 1 ... 128 sliding
129 ... 4096 recur-
sive
Reserve Binary
unsigned
short
16 No effect
The factory data is accepted.
Measurement program Binary
unsigned
short
16 1 ... 6 1 ... EDGEHL
2 ... EDGELH
3 ... DIA
4 ... GAP
5 ... SEG 2 4
6 ... 2-SEG
Number of segments Binary
unsigned
short
16 1, 2, 3, 4 1 ... EDGEHL,
EDGELH, DIA, GAP,
SEG 2 4
2 ... 4 bei MULTISEG
Front edge
segment 1 + 2
1. Segment
2. Segment
Binary
unsigned
short
Low-Byte
High-Byte
16 0 ... 80
0 ... 80
Example:
front edge 1. Seg.
= 2
front edge 2. Seg.
= 4
= 0x0402 hex
(= 1026 decimal)
Front edge
Segment 3+4
Binary
unsigned
short
16
0 ... 80
0 ... 80
Reserve Binary
unsigned
short
16
Reserve Binary
unsigned
short
16
Rear edge
Segment 1 + 2
1. Segment
2. Segment
Binary
unsigned
short
Low-Byte
High-Byte
16
0 ... 80
0 ... 80
Example:
rear edge 1. Seg.
= 8
rear edge 2. Seg.
= 7
= 0x0807 hex
(= 1800 decimal)
Rear edge
Segment 3+4
Binary
unsigned
short
16
0 ... 80
0 ... 80
Reserve Binary
unsigned
short
16
Reserve Binary
unsigned
short
16
Place-holder Binary
unsigned
short
16 No effect. The factory data are accept-
ed.
Master value Binary
float
32 -40.000 ...
+40.000
Entry is made in mm
Fig. 51 Measurement program data record
