Measure
optoCONTROL 2600
6.6.3.12 Read Measurement Program Data
Command:
Byte 1 Byte 2 Byte 3 Byte 4 hex
„+“ „+“ „+“ 0x0D 0x0D2B2B2B
„0“ „D“ „C“ „1“ 0x3143444F
0x26 0x20 0x00 0x00 0x00002026
Response:
Byte 1 Byte 2 Byte 3 Byte 4 hex Remark
„0“ „D“ „C“ „1“ 0x3143444F
0x26 0xA0 0x16 0x00 0x0003A026 Without error
0x26 0xE0 0x03 0x00 0x0003E026 Error + 4 bytes
error code
Measurement program
number
Binary - 0x0007 USER2-Measurement program
Measurement program
name
ASCII - 0x45 „E“
0x44 „D“
0x47 „G“
0x45 „E“
0x48 „H“
0x4C „L“
0x55 „U“
0x00 ZERO
Place-holder Binary - 0x0000...0xFFFF
Analog offset Binary - 0x00000000 0.0 VDC
Analog gain Binary - 0x3F800000 1.0
Display offset Binary - 0x00000000 0.0 mm
Display gain Binary - 0x3F800000 1.0
Upper limit Binary - 0x42200000 40.0 mm
Lower limit Binary - 0x00000000 0.0 mm
Upper warning Binary - 0x42200000 40.0 mm
Lower warning Binary - 0x00000000 0.0 mm
Reserve 1 Binary - 0x0000
Measurement mode Binary - 0x0000 NORMAL
Median Binary - 0x0003 over 3 values
Number of averages Binary - 0x0001 1
Reserve 2 Binary - 0x0000
Measurement program Binary - 0x0001 Edge HL
Number of segments Binary - 0x0001 Edge HL, LH, Diameter, Gap
Front edge for Segment
1+2
Binary - 0x0000
Front edge for Segment
3+4
Binary - 0x0000
Reserve 4 Binary - 0x0000
Reserve 5 Binary - 0x0000
Rear edge for Segment
1+2
Binary - 0x0000
Rear edge for Segment
3+4
Binary - 0x0000
Reserve 7 Binary - 0x0000
Reserve 8 Binary - 0x0000
Place-holder Binary - 0x0000...0xFFFF
Master value Binary - 0x00000000 0,0 mm
Fig. 50 Measurement program data
