6.6.3.1 Information Command
Name
INFO
Description: After the command response, sensor data are sent in the ASCII
format.
Command:
Byte 1 Byte 2 Byte 3 Byte 4 hex
„+“ „+“ „+“ 0x0D 0x0D2B2B2B
„0“ „D“ „0“ „1“ 0x3143444F
0x11 0x20 0x00 0x00 0x00002011
Response with error:
Byte 1 Byte 2 Byte 3 Byte 4 hex Remark
„0“ „D“ „C“ „1“ 0x3143444F
0x11 0xE0 0x03 0x00 0x0003E011 With error +
4 bytes error code
0x06 0x00 0x00 0x00 0x00000006 Error code
0x00000006 Flash access error
Response without error:
Byte 1 Byte 2 Byte 3 Byte 4 hex Remark
„0“ „D“ „C“ „1“ 0x3143444F
0x11 0xA0 0x10 0x00 0x0010A011 without error
ArticleNumber: ‘98765432‘ ASCII - 8 Byte
SerialNumber: ‘1234567‘ ASCII - 8 Byte
Option: ‘000 ‘ ASCII - 8 Byte
Measurement range (mm): 40 Binär - 0x28000000
Reserve: Binär - 0xDE83EB3D
SoftArtBoot: ‘Std ‘ ASCII - 4 Byte
SoftArtArm: ‘Std ‘ ASCII - 4 Byte
SoftArtDSP: ‘Std ‘ ASCII - 4 Byte
SoftVersionBoot: 1003 Binär - 0xEB030000
SoftVersionARM: 1006 Binär - 0xEE030000
SoftVersionDSP: 1002 Binär - 0xEA030000
6.6.3.2 Start Command
Name
START
Description: Starts the permanent measurement output of the sensor.
Command:
Byte 1 Byte 2 Byte 3 Byte 4 hex
„+“ „+“ „+“ 0x0D 0x0D2B2B2B
„0“ „D“ „0“ „1“ 0x3143444F
0x22 0x20 0x00 0x00 0x00002022
Response:
Byte 1 Byte 2 Byte 3 Byte 4 hex Remark
„0“ „D“ „C“ „1“ 0x3143444F
0x22 0xA0 0x03 0x00 0x0003A022 Without error
0x00 0x00 0x00 0x00 0x00000000 Error code
