MICRO-EPSILON optoCONTROL 2600 - Technical Data

Page 11
Measure
optoCONTROL 2600
3.5 Technical Data
Model ODC 2600-40 ODC 2600-40(209)
Measuring range 40 mm
Min. target size 0.3 mm
Distance light source - receiver
(free space)
1
300 (±50) mm 400 (±50) mm
Measuring distance (target - receiver) 150 (±5) mm 200 (±5) mm
Measuring rate 2.3 kHz
Resolution
1
0.1 µm
Linearity
2
< ±3 µm
Repeatability
2 3
≤ ±1 µm ≤ ±1.5 µm
Light source red LED 625 nm
Analog output 0 to 10 VDC, ±10 VDC, selectable
Digital interface RS232 (115.2 kBaud); RS422 (691.2 kBaud)
Switching output Error, 4 x limit values; max. 30 V DC ≤ 100 mA
Signal input Zero setting/reset; trigger/light (on/off); synchronization
Digital output Synchronization
4
Connection Receiver integrated cable, length 2 m 12-pole
Light source integrated cable, length 2 m, 5-pole
Controller Receiver: 12-pole M8 socket;
Light source: 5-pole socket for light source
Supply: 3-pole socket; signal: 25-pole SUB-D socket
Mounting Mounting rail (see accessories), mounting holes
Temperature range Storage -20 °C … +70 °C (non-condensing)
Operation 0 °C ... +50 °C (non-condensing)
Supply voltage +24 VDC (±15 %)
Max. current consumption < 1 A
Shock (DIN EN 60068-2-27) 15 g / 6 ms
Vibration (DIN EN 60068-2-6) 2 g / 20 … 500 Hz
Protection class
(DIN-EN 60529)
Receiver/Light source IP64
Controller IP40
Material Receiver/Light source Aluminum housing
Weight Light source 450 g
Receiver 800 g
Controller 1200 g
Mounting rail 900 g 1100 g
Measuring programs Edge light-dark; Edge dark-light;
(Outside) diameter/width
Gap/(inside diameter)
Any segment edge
Control and display elements LCD display (value, maximum, minimum, peak-to-peak)
Measurement chart in mm / inch, selectable;
Menu language in German / English, selectable
3x LED (power on, light on, error)
Features 4 editable user programs
The specified data apply for a consistent room temperature of 20 °C, after a warm-up time of 30 min.
1) Resolution of the digital display (resolution of digital output 0.6 µm)
2) Measured with 3 sigma; edge measurement without averaging, working distance 150±5 mm, option 209: 200 mm
± 5 mm
3) Measured with static noise over 3 min.
4) Only for synchronization of two or more optoCONTROL 2600 models
