MICRO-EPSILON optoCONTROL 2600 User Manual

Page 48
Measure
optoCONTROL 2600
6.6.3.9 Read Option Data
Name
RD OPT RAM
Description: With this command the currently valid option data is read out from
the main memory.
Command:
Byte 1 Byte 2 Byte 3 Byte 4 hex
„+“ „+“ „+“ 0x0D 0x0D2B2B2B
„0“ „D“ „C“ „1“ 0x3143444F
0x25 0x20 0x00 0x00 0x00002025
Response:
Byte 1 Byte 2 Byte 3 Byte 4 hex Remark
„0“ „D“ „C“ „1“ 0x3143444F
0x25 0xA0 0x0D 0x00 0x000DA025 Without error
0x25 0xE0 0x03 0x00 0x0003E025 Error + 4 bytes
error code
Measurement program
number
Binary - 0x0000 Std. - Measurement program
EDGEHL
Language Binary - 0x0001 English
Displayed measurement unit Binary - 0x0000 mm
Error handling, analog Binär - 0x0000 Error output
Serial output format Binary - 0x0000 Binary
External light control Binary - 0x0000 Not active
Light intensity Binary - 0x0032 50 %
Thresshold value for dark/
light transition / Contrast
Binary - 0x3232 50 % / 50%
Reserve 2 Binary - 0x0000
Active interface Binary - 0x0001 RS232
RS232 Baud rate Binary - 0x0001C200 115200 Bd
RS232 Parity Binary - 0x0000 None
RS232 Stop bits Binary - 0x0002 2
RS232 TimeOut Transmit Binary - 0x0001 No effect
RS232 TimeOUT Receive Binary - 0x0001 No effect
RS422 Baud rate Binary - 0x000A8C00 691200 Bd
RS422 Parity Binary - 0x0000 None
RS422 Stop bits Binary - 0x0002 2
RS422 TimeOut Transmit Binary - 0x0001 No effect
RS422 TimeOUT Receive Binary - 0x0001 No effect
6.6.3.10 Write Option Data
Name
WR OPT TO RAM
Description: With this command option data is written from the receive buffer
to the main memory. The validity of the data is checked while this
occurs. If incorrect data is found or a different error arises, the data
is not accepted into the main memory.
Command:
Byte 1 Byte 2 Byte 3 Byte 4 hex
„+“ „+“ „+“ 0x0D 0x0D2B2B2B
„0“ „D“ „C“ „1“ 0x3143444F
0x27 0x20 0x0B 0x00 0x000B2027
