MICRO-EPSILON optoCONTROL 2600 User Manual

Page 49
Measure
optoCONTROL 2600
Description Format
Typ
Bits Valid Values Remark
Measurement program
number
Binary
unsigned
short
16 0...5, Standard
6...9, User - if
available in flash
memory
6 - USER1
...
9 - USER4
Language Binary
unsigned
short
16 0, 1 0 ... German
1 ... English
Displayed measurement
unit
Binary
unsigned
short
16 0, 1 0 ... mm
1 ... inch
Error handling display +
analog output
Binary
unsigned
short
16 0, 1 0 ... Error output
:
-- , ---
10,04 V
1 ... retain last
value
Serial output format Binary
unsigned
short
16 0, 1 0 ... binary
1 ... ASCII
External switching of the
light source
Binary
unsigned
short
16 0, 1 0 ... not active
1 ... active
Light intensity Binary
unsigned
short
16 No effect. The factory data are accept-
ed.
Threshold value for dark/
light transition
Binary
unsigned
short
8 20 ... 90 20 ... 90 %
Contrast Binary
unsigned
short
8 0 ... 100 0 ... 100 %
Reserve 2 Binary
unsigned
short
16
Active serial interface Binary
unsigned
short
16 0, 1 0 ... RS422
1 ... RS232
RS232 Baud rate Binary
integer
32 9600, 19200
38400, 115200
RS232 Parity Binary
unsigned
short
16 0, 1, 2 0 ... No
1 ... Even
2 ... Odd
RS232 Stop bits Binary
unsigned
short
16 1, 2
RS232 Timeout transmis-
sion
Binary
unsigned
short
No effect
The factory data is accepted.
RS232 Timeout
receipt
Binary
unsigned
short
16 No effect
The factory data is accepted.
Fig. 49 Option data record
