Measure
optoCONTROL 2600
6.6.3.18 Reset the Light Reference Tuning
Name
RESET LIGHT REFERENCE TUNING
Description: Erasures the flexible threshold value for dark/light transition, use of
a fixed threshold value for dark/light transition.
Command:
Byte 1 Byte 2 Byte 3 Byte 4 hex
„+“ „+“ „+“ 0x0D 0x0D2B2B2B
„0“ „D“ „C“ „1“ 0x3143444F
0x2D 0x20 0x00 0x00 0x0000202D
i
This command corresponds to the menu “1B30 - Reset Light Reference Tuning“.
Response:
Byte 1 Byte 2 Byte 3 Byte 4 hex Remark
„0“ „D“ „C“ „1“ 0x3143444F
0x2E 0xA0 0x03 0x00 0x0003A02E Without error
0x00 0x00 0x00 0x00 0x00000000 Error code
6.6.4 Error Responses
0x04 Too much data received
0x06 Flash access error
0x0a Error on writing to the RAM
0x0b Incorrect data transmitted, see, ‘Valid values’
0x0c Incorrect measurement program number
0x01 Error destination, if µC has to send information or data an error message is
returned e.g. passing data to the DSP were aborted
0x02 Error source, error during data fetching
0x03 Error length, stated length in the parameter > buffer size receiver
0x05 Not used
0x07 Error erase flash
0x08 Error flash sector, during writing or deletion of the flash
0x09 Error video, video can not be fetched by the DSP
