Version 1.10 Page 66 of 203
Figure 44– Example: bars with gap
A practical configuration example of a system of 30 m could be the following:
Starting block—50 cm – 13 meters OJ – hurdle – 8 meters – hurdle – 8 meters – hurdle – 1 meter
Figure 45 – Configuration of bar blocks
