4.0 Configuration
I/O Port Rule Define
Set the type of I/O rules to perform:
Disabled: Outputs have no logical connection to inputs.
Default Rules:
Each input has a logical connection to each output as follows:
Input 1 -> Output 1
Input 2 -> Output 2
Input 3 -> Output 3
Input 4 -> Output 4
Custom Rules:
User can make custom rules to trigger output states. Custom rules can
contain any of the following I/O rules:
 A timer has finished counting down
 A input signal has changed state
 A combination of a input state and a timer.
Values (selection)
Disable
Default Rules
Custom Rules
Rule Name
Each I/O rule must have a unique name. This is for reference purposes and
has no effect on the rule itself.
Values (characters)
rule0
I/O Rule Mode
Define the parameters of the desired rule:
Use Timer Only: Once the programmed timer has expired, the defined
output state will be triggered.
Use Input States Only: The VIP4G will set puts as defined based on input
states.
Use Input States With Timer: A combination of inputs states and a timer
would trigger an output action when the input state if changed for more
than the specified time.
Values (selection)
Use Timer Only
Use Input States Only
Use Input States With
Timer
