© Microhard Systems Inc. 83
4.0 Configuration
Select HT20 for a 20MHz channel, or HT40 for a 40 MHz Channel.
The 40MHz channel is comprised of 2 adjacent 20MHz channels and
the + and—designate to use the higher or lower of the adjacent
channels.
High Throughput Mode
Values (selection)
HT20
HT40-
HT40+
The Channel-Freq setting allows configuration of which channel to operate on, auto can be chosen where
the unit will automatically pick a channel to operate. If a link cannot be established it will try another
channel.
Channel-Freq
2.4 GHz Channels
Auto
Channel 01 : 2.412 GHz
Channel 02 : 2.417 GHz
Channel 03 : 2.422 GHz
Channel 04 : 2.427 GHz
Channel 05 : 2.432 GHz
Channel 06 : 2.437 GHz
Channel 07 : 2.442 GHz
Channel 08 : 2.447 GHz
Channel 09 : 2.452 GHz
Channel 10 : 2.457 GHz
Channel 11 : 2.462 GHz
5 GH Channels
Auto
Channel 36: 5.18 GHz
Channel 40: 5.2 GHz
Channel 44: 5.22 GHz
Channel 48: 5.24 GHz
Channel 149 : 5.745 GHz
Channel 153 : 5.765 GHz
Channel 157 : 5.785 GHz
Channel 161 : 5.805 GHz
Channel 165 : 5.825 GHz
The Wireless Distance parameter allows a user to set the expected
distance the WiFi signal needs to travel. The default is 10km, so the
VIP4G will assume that the signal may need to travel up to 10km so it
sets various internal timeouts to account for this travel time. Longer
distances will require a higher setting, and shorter distances may
perform better if the setting is reduced.
Wireless Distance
Values (meters)
10000
Advanced Capabilities (Only shown if box is checked)
MPDU Aggregation (Enable/Disable) - Allows multiple data frames to be sent in a single transmission
block, allowing for acknowledging or retransmitting if errors occur.
Short GI (Enable/Disable) - GI (guard interval) is the time the receiver waits for any RF reflections to settle
before sampling data. Enabling a short GI (400ns) can increase throughput, but can also increase the error
rate in some installations.
HT Capabilities Info - TX-STBC RX-STBC1 DSSS_CCK-40
Maximum AMSDU (byte) - 3839
Maximum AMPDU (byte) - 65535
