4.0 Configuration
Image 4-12-6: Tools > Modbus Configuration
4.12.5 Tools > Modbus
4.12.5.1 Modbus > TCP Modbus
The VIP4G can be configured to operate as a TCP/IP or Serial (COM) Modbus slave and respond to
Modbus requests and report various information as shown in the Data Map.
Status
Disable or enable the Modbus service on the VIP4G.
Values (selection)
Disable Service
Enable Service
TCP Mode Status
Disable or enable the Modbus TCP Connection Service on the VIP4G.
Values (selection)
Disable
Enable
