Microhard Systems VIP4G - AT Command Line Interface; AT Command Overview

© Microhard Systems Inc. 166
5.0 AT Command Line Interface
5.1 AT Command Overview
AT Commands can be issued to configure and manage the VIP4G, serial port (Serial), or by TCP/IP
(telnet).
5.1.1 Serial Port
To connect and access the AT Command interface on the VIP4G, a physical connection must be made on
the RS232 DB9 serial port labeled ‘Serial’. A terminal emulation program (Hyperterminal, Tera Term,
ProComm, Putty etc) can then be used to communicate with the VIP4G.
Image 5-1: Serial Port Settings
Default Settings:
Baud rate: 115200
Data bits: 8
Parity: None
Stop Bits: 1
Flow Control: None
Once communication is established, a login is required to access the AT Command interface, once logged
in, the AT Command Line Interface menu is displayed. Type “?” or Help to list the menu commands.
Default Settings:
VIP4G login: admin
Password: admin
Image 5-2: AT Command Window
