1.0 Overview
1.2 Specifications (Continued)
Management: Local Serial Console, Telnet, WebUI, SNMP, FTP &
Wireless Upgrade
Diagnostics: Status LED’s, RSSI, Ec/No, Temperature, Remote Diagnostics,
Watchdog, UDP Reporting
Digital I/O: 4 Inputs / 4 Outputs
GPS:
Navigation Update Rate: Up to 5 Hz
Accuracy: Position: 2.5 m CEP
SBAS: 2.0 m CEP
Acquisition: Cold Starts: 27 seconds
Aided Starts: 4 seconds
Hot Starts: 1 second
Sensitivity: Tracking: -159 dBm
Cold Starts: -147 dBm
Hot Starts: -156 dBm
Environmental
Operation Temperature: -40
o
F(-40
o
C) to 185
o
F(85
o
C)
Humidity: 5% to 95% non-condensing
Mechanical
Dimensions: 5.65” (145mm) X 3.72” (95mm) X 1.20” (30mm)
Weight: Approx. 405 grams
Connectors:
Antenna: Wi-Fi: 2x RP-SMA Female
Cellular: 2x SMA Female (Main, DIV)
GPS: 1x SMA Female (Supports Active & Passive Antennas with LNA)
Data: RS232 Data: DE-9 Female
RS485: SMT: 6-Pin Micro MATE-N-LOK AMP 3-794618-6
Mating Connector: 6-Pin Micro MATE-N-LOK AMP 794617-6
Ethernet : 4x RJ-45
PWR, Misc: Power: SMT: 4-Pin Micro MATE-N-LOK AMP 3-794618-4
Mating Connector: 4-Pin Micro MATE-N-LOK AMP 794617-4
Misc: Digital I/O: SMT: 10-Pin Micro MATE-N-LOK AMP 4-794618-0
Mating Connector: 10-Pin Micro MATE-N-LOK AMP 1-794617-0
IP67 Enclosure (Optional):
Dimensions: Approx: 8.4”(213mm) X 7.2”(182mm) X 1.75” (44mm)
Weight: Approx: 1.25 kg
