© Microhard Systems Inc. 56
4.0 Configuration
Subnet IP Address
The is the IP Address of the remote network, on the remote side of the
GRE Tunnel.
Values (IP Address)
(varies)
Gateway IP Address
Enter the WAN IP Address of the VIP4G or other GRE supported device in
which a tunnel is to be created with at the remote end.
Values (IP Address)
(varies)
Subnet Mask
The subnet mask for the local network/subnet.
Values (IP Address)
(varies)
Subnet IP Address
Enter the subnet address for the local network.
Values (IP Address)
(varies)
Remote Setup
The remote setup tells the VIP4G about the remote end, the IP address to create the tunnel to, and the
subnet that is accessible on the remote side of the tunnel.
Subnet Mask
The is the subnet mask for the remote network/subnet.
Values (IP Address)
(varies)
IPsec Setup
Refer to the IPsec setup in the VPN Site to Site section of the manual for more information.
For an example of how to set
up a GRE Tunnel, refer to the
Appendix: GRE Example.
