4.0 Configuration
Set the time (seconds) in which to advertise this CRP (Candidate
Rendezvous Point).
time
Values (seconds)
(none)
The priority determines how important this CRP is compared to others.
The lower the value, the more important the CRP.
Priority
Values (integer)
(none)
This field is used to set up which port (IP address) is used as the
Candidate Bootstrap Router.
Candidate Bootstrap Router
Values (selection)
Varies based on configured
interfaces
Candidate RP Configuration
The RP Point Configuration is for static Rendezvous Point Configurations. The argument can be either a
unicast address or a multicast group, with optional group address, mask length, and priority arguments as
seen below.
Image 4-2-13: Network > PIM-SM Configuration
If the static RP is a unicast address, enter that address here.
RP Point IP
Values
(none)
Enter the optional multicast group IP here for the RP.
Group IP
Values
(none)
