MSB780(X) - User’s Guide
Table 9 – continued from previous page
Command Short description Page
addr
change the address in POLL mode.
44
addr?
get actual address in POLL mode.
44
open
access to command mode in POLL mode.
44
close
close command mode in POLL mode.
44
send
read the output message in POLL mode.
45
unit
change the measurement unit.
45
unit?
get actual measurement unit.
46
cnfdef
set default config (HQFE, HQNH, TQFE, seri).
46
terminal rs232
temporarily redirect RS232 to service port.
46
terminal rs485
temporarily redirect RS485 to service port.
47
terminal probe
temporarily redirect probe to service port.
47
dir e:
print list of files.
47
type <filename>
print file.
48
xmodemr E:\<filename>
read file using XMODEM
48
cset
set coefficient ’k’ and ’q’ ( Po = k*Pm + q ).
49
dpmax
set the maximum permissible difference pres-
sure.
50
dpmax?
get the maximum permissible difference pres-
sure.
50
adjdef
set default adjust config.
51
icaomode
set calculation mode for QNH and QFE
51
icaodigits
sets number of decimal spaces (truncating) for
QNH and QFE in ICAO mode
51
hqfe
set altitude for QFE corrected pressure.
52
hqnh
set altitude for QNH corrected pressure.
53
tqfe
set temperature for QFE corrected pressure.
55
tqfea
set temperature for QFE without saving to
FLASH.
55
hhcp
set height difference for HCP level.
55
hqfe?
get altitude for QFE corrected pressure.
56
hqnh?
get altitude for QNH corrected pressure.
56
tqfe?
get default temperature for QFE corrected pres-
sure.
56
tqfea?
get actual temperature for QFE corrected pres-
sure.
56
hhcp?
get height difference for HCP level.
56
flash
switch to bootloader.
-
dt
show date and time.
57
setdt
set date and time.
57
setpin
set PIN code for enable settings via LCD
57
amode
set analog output mode and range.
79
asel
set analog output quantities.
80
atest
analog output test.
81
aerr
analog output fault indication setting.
81
Continued on next page
32
