MSB780(X) - User’s Guide
The barometer will echo characters since now.
Echoing is not supported on some ports. In that case the answer is "Not supported on this
channel ! <cr><lf>".
6.12 “echo0” Disable echo
To disable echoing characters on the port currently connected, use this command.
Example:
echo0<cr>
Echo is OFF<cr><lf>
The barometer will not echo characters since now.
6.13 "form" Change output message format
This command is used to set a format of the message being output by MSB780 or MSB780X
after SEND<cr> command, or automatically if run mode is on. The format string can be up to 126
characters long.
Table 11: Form command fields
Field Description
/ Restore the message to default. Use alone.
0.0 Restore default number formats.
x.y Set number of digits and decimal places.
quantity Quantity value or * characters if value not available.
U Unity symbol as it is (width depends).
U1 ... U9 Unit symbol in the specified number of characters (truncated or space filled
as necessary).
"xxx" String constant (free text).
P Pressure output
P1 Pressure output from transducer 1, same format as P.
P2 Pressure output from transducer 2, same format as P.
P3 Pressure output from transducer 3, same format as P.
QNH QNH calculation
QFE QFE calculation
HCP HCP calculation
P3H Pressure trend
A3H Pressure tendency
TP1 Temperature of pressure transducer 1
Continued on next page
39
