MSB780(X) - User’s Guide
amode x<cr>
wait.. OK<cr><lf>
The analog output is now turned off.
Important: After setting range, remember to set also the AERR value.
9.2 “asel” Analog output quantity and scale
This command is used to select a quantity and range to be displayed on the analog output.
Commands and parameters are not case sensitive.
Command:
1. without parameter: print actual settings
2. "off" parameter: turn analog output off
3. four parameters: quantity, unit , min, max. Set analog output for chosen quantity and unit.
The output will be scaled according min, max limits.
Example setup:
asel p hpa 900 1100<cr>
wait.. OK<cr><lf>
The analog output will display values of pressure in range 900 hPa to 1100 hPa.
Example without parameters:
asel<cr>
Insert parameters: quantity(or "off" to turn off analog
output) unit min max<cr><lf>
Actual analog out quantity: P<cr><lf>
Quantity minimum : 900.000 hPa<cr><lf>
Quantity maximum : 1100.000 hPa<cr><lf>
You can see available quantities in Table 21 on page 82.
80
