MSB780(X) - User’s Guide
Table 18: Verification result interpretation
Reply Interpretation
+1+0+0+0+0 ADC error
+0+1+0+0+0 Flash CRC error
+0+0+1+0+0 Copensation RH sensor error
+0+0+0+1+0 Flash memory failure
+0+0+0+0+1 Pressure measuring error
For R0 command the values of pressure are alwais in basic unit [hPa].
8.12 aR1! Continuous Measurement (user units)
This command returns last measured value of pressure. (Pressure is measured periodically,
new data is available each measurement period, see Parameters of sensor)
The output message format is “pressure QFE pressure QNH pressure”.
Example:
0R0!<cr>0+1009.066+1009.066+1021.121<cr><lf>
For R1 command the values of pressure are in user defined units for each quantity separately.
For unit preferences see command unit on page 45. For list of quantities and available units
see Table 21 on page 82.
8.13 aV! Get Verification
This command starts the verification procedure.
0V!<cr>00005<cr><lf>
A subsequent 0D0!<cr> command returns verification result.
Example:
0D0!<cr>0+0+0+0+0+0<cr><lf>
8.14 aXD1! Send data command from transducer 1
This command is used to get data from the sensor, specifically from transducer 1. If MSB780
has more then one transducer, it can be use commands aXD2!<cr> from transducer 2 and
76
