MSB780(X) - User’s Guide
6.27 “unit?” Get actual measurement unit
This command lists all quantities and actual unit of each.
6.28 “cnfdef” Set default configuration
This command reverts configuration to factory defaults, i.e.: - default units (hPa) for all pressure
quantities, - zero values for hqnh, hqfe, hhcp, - tqfe and tqfea temperature for QFE calculation
to 20
◦
C, - maximum permissible pressure difference between transducers (DPMAX) to 1.0
hPa, - ICAO mode for calculation QFE and QNH corrected pressures, no truncating of results,
- PIN code for enable setting via LCD to "1234", - output message format (FORM) set to "\33
4.2 P \RN", - analog output turned off, - quantity alarm turned off, - recording quantities set to
pressure, external temperature and humidity, - recording periode set to 10 seconds per sample,
- LCD screens configuration (shown quantities), - default configuration for ports, see 13.
Table 13: Default port configuration parameters
Default configuration parameters
Parameter RS232 RS485 Unit
UART Baud rate 9600 9600 Baud
UART parity None None
UART data bits 8 8
UART stop bits 1 1
UART SMODE RUN POLL
UART intv time 1 10 s
Example:
cnfdef<cr>
CNFDEF:<cr><lf>
Set default config? (yes/no): yes<cr>
Default config – OK<cr><lf>
wait..OK<cr><lf>
This command has no impact on adjustment coefficients k and q.
6.29 “terminal rs232” Temporarily redirect the service port to RS232
This command may be used only on the service port. It redirects the service port to RS-232
port.
This command is useful when configuring the barometer using service port. It enables user to
change settings of RS-232 like Baud rate, data bits, stop bits, echo, interval and smode.
46
