MSB780(X) - User’s Guide
Table 20: Analog output ranges
Parameter Range
a 0 .. 1 V
b 0 .. 5 V
c 0 .. 10 V
d 0 .. 20 mA
e 4 .. 20 mA
x OFF
• from 0 V to 1 V
• from 0 V to 5 V
• from 0 V to 10 V
• from 0 mA to 20 mA
• from 4 mA to 20 mA
For wiring see figure 14 on page 23.
Settings of analog output can be altered using LCD (Menu->Interfaces->Analog output, see on
page 68) or using serial commands (see next paragraphs).
9.1 “amode” Set analog output range
To set the analog output output range, use the amode command.
Example:
amode<cr>
Actual mode: 0 .. 10 V<cr><lf>
Please select range/mode:<cr><lf>
a) 0 .. 1 V<cr><lf>
b) 0 .. 5 V<cr><lf>
c) 0 .. 10 V<cr><lf>
d) 0 .. 20 mA<cr><lf>
e) 4 .. 20 mA<cr><lf>
x) OFF<cr><lf>
empty = exit<cr><lf>
Your choice: c<cr>
wait.. OK<cr><lf>
The analog output is now set as voltage output from 0 to 10 V.
To turn the analog output off:
79
