MSB780(X) - User’s Guide
For example, the user would like to set the RS-232 baud rate via service port.
First the user redirects to the RS232 port:
terminal rs232<cr>
Terminal mode is active. Close it with command "tclose"
!<cr><lf>
RS232 >
Now it is possible to enter commands as if the user was connected via RS-232 port.
seri<cr>
SERI: [baud parity databits stopbits] for example "9600 n 8 1"
New values: "19200 n 8 1"<cr>
wait..OK<cr><lf>
A new Baud rate has been set for RS-232. To cancel the redirection to the RS-232 port, send:
tclose<cr>
Terminal mode was closed !<cr><lf>
6.30 “terminal rs485” Temporarily redirect the service port to RS-485
This command works in the same way as the previous command, but for RS-485.
6.31 “terminal probe” Temporarily redirect the service port to external
probe
This command is supported only on service port. It is used for communication with external
probe which is connected to RS485 port of the barometer. After issuing this command the
barometer prints the status of external probe (whether the probe is or is not responding) and it
resets the external probe by turning off and on its power supply. This command actually makes
the barometer to be a service port to RS485 converter.
6.32 "dir e:" Print list of files
The dir e:<cr> command lists all the files from the internal memory.
47
