MSB780(X) - User’s Guide
Table 11 – continued from previous page
Field Description
TP2 Temperature of pressure transducer 2
TP3 Temperature of pressure transducer 3
DP12 Pressure diference (P1 - P2)
DP13 Pressure diference (P1 - P3)
DP23 Pressure diference (P2 - P3)
\N Line feed character. <0x0A>.
\R Carriage return character. <0x0D>.
\RN Carriage return and line feed characters. <0x0D><0x0A>.
\T Horizontal tabulator character <0x09>.
\0...\255 Data byte with the specified decimal value.
ADDR Device address (left - filled with spaces).
CS2 Modulus-256 checksum of message sent so far, hexadecimal format.
CS4 Modulus-65536 checksum of message sent so far, hexadecimal format.
CSX NMEA XOR checksum of message sent so far, hexadecimal format.
ERR Error flags for P
1
, P
2
and P
3
(if installed, right - filled with spaces); 0 = no
error, 1 = error.
SN Device serial number.
The default output format depends on the device configuration.
Prompt syntax and output example:
form<cr>
Write formatted string for FORM: \33 4.2 P \RN<cr>
FORM format is OK<cr><lf>
|! 997.34<cr><lf>
|<cr><lf>
wait..OK<cr><lf>
send<cr>
! 997.33<cr><lf>
Prompt syntax and output example 2:
form<cr>
Write formatted string for FORM: "! P:" 0.3 P ", QFE:" 0.3 QFE ", QNH:" 0.3 QNH
", TP:" 0.2 TP1 ", err:" ERR ", baroSN:" SN ", CS:" CS4 \RN<cr>
FORM format is OK<cr><lf>
|! P:981.811, QFE:984.929, QNH:1014.641, TP:27.75, err:000, baroSN:MSB780X-2.0-1709-1DTS-054,
CS:1620<cr><lf>
|<cr><lf>
wait..OK<cr><lf>
send<cr>
! ! P:981.834, QFE:984.952, QNH:1014.653, TP:27.02, err:000, baroSN:MSB780X-2.0-1709-1DTS-054,
CS:161A<cr><lf>
Restoring the default output message (depends on the device configuration) and output exam-
