MM182-001 – Operator Manual
Connect the Ø40 mm pipe to the waste disposal
unit drain and block it with the strap.
Fix the pipe to the collar on the unit.
Connect the flexible drain pipe as shown in chapter 2.5.9.
Do not connect it to the sewer system and in any case follow current regulations.
The laboratory’s drain system must be suitable for use of a waste disposal unit.
Secure the pneumatic ON/OFF button in the
position indicated in the photo and connect it to
one end of the pipe.
Connect the other end of the black pipe to the
waste disposal unit. Be careful not to crush the
pipe.
Connect the power cable as explained in chapter
5.10.1.
Installation is finished.
Before using the waste disposal unit, read the following notes carefully.
