159
5.51.2. Technical specifications
• The internal power supply wattage: 24W
• Thermal output: 35.72 BTU/h
• Max consumption: 10.47W
• Inlet: 100 - 240V~. 1-0.5A, 50-60Hz
• Dimensions (H x L x D): 1,75"(44.45mm) x 8.5"(215.9mm) x 10"(254mm)
• Weight: 3.54lb; 1.61Kg
• 8 ports RJ45 10/100/1000Mbps half/full duplex
• 2GbE RJ45 interfaces and 2GbE SFP interfaces
• Compact 1 RU half-width form factor
• Data rates up to 176Gbps (full duplex) and a forwarding rate of up to 164Mpps
• Four 10GbE SFP+ ports for high-speed uplinks and a stacking architecture up to four units at 40Gbps
• Switch stacks up to 196 1GbE ports that can be managed from a single screen or IP address
• Working temperature from 32°F(0°C) to 113°F (45°C)
• Fanless operation at 95% relative humidity
• Storage temperature: from -40°C (-40°F) to 65°C (149°F)
• Fabric switch capability (full duplex): 24Gbps
• Forwarding speed: 18Mpps
• CPU Memory: 1GB
• Flash Memory: 1GB
• Pocket memory buffer: 1.5MB
Switch Settings
• The ETH switch is already programmed with these functions:
- Loop control (anti looping) setting
- Spanning Tree Protocol (STP) application
- The 802.1d Spanning Tree is a standard level 2 switch requirement that enables bridges to
automatically prevent and resolve level 2 forwarding loops.
- Switches exchange configuration messages using specifically formatted frames, selectively
enable and disable forwarding on ports.
- Broadcast detection at 1536 for all the 8 ports
- Monitoring abnormal data or issues at level 3 (network) of model ISO OSI
