2. Connect the input port of the video printer and the output of the ultrasonic system with the
data cable (S-Video or coaxial cable).
3.
T
o print with the <Print> key or the foot
switch, please connect the “REMOTE” port of the video printer and the “REMOTE” port of the ultrasonic system with the remote cable.
4. Connect the power input port of the video printer and the “AC out” of the ultrasonic system
with the power cord of video printer.
5. Turn on the ultrasonic system and the video printer.
2.1.7
2.2
Connecting an External Display
1. Turn off the ultrasonic system and the external display.
2. Connect the VGA out of the ultrasonic system and the VGA input of the external display.
3. Turn on the ultrasonic system and the external display.
Powering ON/OFF
WARNING:
To ensure safe and effective system operation, you must perform daily
maintenance and checks. If the system begins to function improperly –
immediately stop scanning. If the system continues to function
improperly – fully shut down the system and contact Mindray
Customer Service Department or sales representative. If you use the
system in a persistent improperly functioning state – you may harm
the patient or damage the equipment.
2.2.1 Checking before Powering ON
Please check whether the system and the environment meet the requirements below before
powering on the system.
No. Items Result
1
The temperature, relative humidity and atmospheric pressure shall meet the
requirements of operating conditions.
2 There shall be no condensation.
3
There shall be no distortion, damage or dirt on the system and peripheral
devices.
If any dirt is found, cleaning shall be performed as defined in section “9 Cleaning
and Maintaining the System
”.
4 There shall be no loose screws on the monitor or control panel.
5 The locking mechanism of casters can work normally.
6
There shall be no cable damage (e.g. power cord). Maintaining secure
connections to the system at all times.
7
Check the power cord / power supply and all I / O ports. Ensure that all
connections are free from damage and remain clear of foreign object blockages.
There shall be no obstacles around the system and its air vent.
2-4 Preparing the System
