5-2 Annotating the Image
h Press <Set> to add the selected comment and end adding comments. The cursor
moves to the end of the comments.
Add comments from comments library (select word in the menu)
1. Move cursor to where you want to add comments. Press <Set> to set the initial position.
You can also move the comment later. If initial position is not set, the comments will be
added to behind the last editing position.
2. Press <Menu> to open the comment menu.
3. Select a comment in the menu and press <Set> to activate it and move it to the initial
position.
4. Move the comment with the track ball.
5. Press <Set> to confirm.
5.1.2 Adding Arrow
1. Move cursor to where you want to add arrow. You can also move the arrow later.
2. The “Rotation” indicator of <Multifunctional Knob> lights up. Rotate the <Multifunctional
Knob> to change the direction of the arrow by 15 degrees.
3. Press <Set> to confirm and continue adding arrow or press <Back> to delete the last
arrow. Press <Comment> to exit arrow mode.
5.1.3 Moving Comments/Arrows
1. Move cursor to the comment/arrow that you want to move, and the cursor changes to “ ”.
2. Press <Set> to select the comment/arrow and the cursor changes to the frame of the
comment/arrow.
3. Move the frame of the comment/arrow to a new position with the track ball.
4. Press <Set> to confirm.
5.1.4 Editing Comments
1. Move cursor to the comment to be edited, and press <Set> twice to enter comment editing
status.
2. Move cursor to the editing position with the direction buttons. Press <DEL> to delete the
character on the left of the cursor.
3. Press <Set> to confirm and exit or press <Back> to cancel and delete the current
comment.
5.1.5 Deleting Comments/Arrows
1. Move cursor to the desired comment/arrow and the cursor turns to “ ”. Press <Set> to
select the comment/arrow.
2. Press <Back> or <Del> to delete the comment/arrow.
5.2 Body Mark
Body mark indicates the posture of patients and orientation of transducer during ultrasonic exam. It
is an additional remark to the ultrasonic image.
