6 Auxiliary Functions
6.1
6.1.1
Biopsy Guide
Basic Operations
WARNING:
Do not freeze the image while performing biopsy.
To enter biopsy mode: Press <Menu> to open the B image menu, and then click [Biopsy] to
open the biopsy menu and enter biopsy mode. In M+B mode, you need to switch to B Img
Menu.
In the biopsy menu,
z [NGB Model (Model)]: If the brackets for current transducer are more than one, click this
item to switch brackets.
z [Guideline (All/A/B/C)]: To select the guide line to be displayed.
z [Display (On/Off)]: To display/hide the guide line.
z [Dot Size (Small/Medium/Large)]: To set the size of dots in the guide line.
z [Verify]: Click [Verify] to open the “Biopsy Verify” menu and verify the biopsy guide line.
6.1.2 Adjusting the Guide Line
WARNING:
1. Prior to each puncture, calibrate the needle guide line.
2. If the positions of the needle and needle guide line are not
consistent, do not execute needle guide operation.
NOTE: The B-Mode image must be live and active to verify the onscreen biopsy guideline.
In the “Biopsy” menu, click [Verify] to open the “Biopsy Verify” menu.
In the “Biopsy Verify” menu,
z [Guideline (All/A/B/C)]: To switch among guide lines.
z [Position (Value)]: Move the cursor to this item, and then press <Set> or <Back> to move
the guide line. It is available only when one guide line is displayed.
z [Angle (Value)]: Move the cursor to this item, and then press <Set> or <Back> to
rotate the guide line. It is available only when one guide line is displayed.
z [Save]: To save the direction and position of current guide line.
z [Load Factory]: To load factory configuration of current guide line.
z [Exit]: To return to the “Biopsy” menu and display the guide lines as just set.
Auxiliary Functions 6-1
