8-6 Preset
Panel Panel Function Available Functions
Other
Biopsy Line Display, M-Mark Display, Rotation, 4B,
Clear, Exit, TSI, B, M, Dual, Freeze, Measure,
Comment, Body Mark, Menu, Exam, None
Keyboard preset:
Item Type Description
Key Volume Drop-down list
To set the volume of keyboard sound:
Low/High/None
Trackball Speed Drop-down list
To set the speed of cursor when rolling the track
ball: Slow/Mean/Fast
Preset of Key Config
Key
z Print Analog B/W Video Print
z F1 Save Single frame Image to USB Disk
z F2 Report
z Shift+S Save Single frame Image to Local Disk
Footswitch
z Left Analog B/W Video Print
z Right Freeze
8.2.7 Option
Select an option in the list, click [Install] to install it or click [Uninstall] to un install it.
8.3 Exam Preset
To configure the related parameters of each exam mode.
8.3.1 Exam Selection
“Exam Selection” is used to select available exam modes for a transducer.
1. Select the model of transducer in the “Probe” drop-down list.
2. To select exam modes for the transducer:
z [>]: Select an exam mode in “Exam Library”, and click [>] to add it to “Exam Selected”;
z [>>]: Click [>>] to add all exam modes in the “Exam Library” to “Exam Selected”;
z [<]: Select an exam mode in “Exam Selected”, and click [<] to delete it;
z Sort: Select an exam mode in “Exam Selected”, and click [Move Up] or [Move Down] to
move it up and down. The sequence here is the same as that in the “Exam Mode” menu.
To Next Page
