Annotating the Image 5-3
5.2.1
5.2.2
Adding Body Mark
1. Press <Body Mark> to open the “BodyMark Lib” dialog box.
2. Move cursor to the desired body mark and press <Set> to add the body mark to the image.
3. Roll the track ball to move the transducer mark and rotate the <Multifunctional Knob> to
rotate the transducer mark.
4. Press <Set> to confirm.
In dual B/quad B mode, you can add body mark into the two/four images respectively.
Moving the Body Mark
1. Move cursor to the body mark and the cursor turns to “ ”. Press <Set> to select the body
mark and the cursor turns to the frame of the body mark.
2. Move the frame of the body mark to the desired position with the track ball.
3. Press <Set> to confirm.
5.2.3
5.2.4
Editing the Body Mark
1. Move cursor to the transducer mark of the body mark and press <Set> twice. The cursor
turns to the transducer mark.
2. Roll the track ball to move the transducer mark and rotate the <Multifunctional Knob> to
rotate the transducer mark.
3. Press <Set> to confirm and exit.
Deleting the Body Mark
To delete the body mark:
z Double-click <Body Mark> to delete the body mark of current window.
z Press <Shift> + <Del> to clear all the body marks.
