8.3.2
8.4
Exam Config
To select the applied part of exam modes: Click the cell corresponding to “Application” of each
exam mode and select the applied part in the drop-down list.
To copy parameters of an exam mode to another exam mode
1. Select a source exam mode in the exam modes list.
2. Click [Copy] to copy the parameters of the source exam mode.
3. Select a target exam mode.
4. Click [Paste] to paste the parameters to the target exam mode.
To rename an exam mode
1. Select an exam mode in the exam modes list.
2. Click [Rename] to open the “Rename” dialog box.
3. Input the name of new exam mode.
4. Click [OK] to confirm or click [Cancel] to cancel.
To export parameters of an exam mode
1. Select an exam mode in the exam modes list.
2. Click [Export] to open the “Export Data” dialog box.
3. Select the path of the exported data and name the data.
4. Click [OK] to confirm or click [Cancel] to cancel.
To load parameters of an exam mode
1. Click [Load] to open the “Load Data” dialog box.
2. Select the data to be imported.
3. Click [OK] to confirm or click [Cancel] to cancel.
Export All
1. Click [Export All] to open the “Export Data” dialog box.
2. Select a disk.
3. Click [OK] to confirm or click [Cancel] to cancel.
Others
Select an exam mode, and click [Measure Preset], [Comment Preset] or [Image Preset] to
configure the parameters of the selected exam mode. Refer to relevant chapters for details.
Image Preset
“Image Preset” is used to configure the parameters corresponding to exam modes, image modes
and transducers. For detailed information about the parameters, please refer to “4 Optimizing the
Image”.
1. Select an exam mode.
2. Select an image mode.
3. Select a transducer.
4. Configure the image parameters according to the following tables.
B/THI
Item Type Description
A.Power Drop-down list To set the default acoustic power.
Preset 8-7
