17 Probes and Biopsy
NGB-031
Perform the following procedure:
1. Install the needle-guided bracket.
a. Put on the sterile probe sheath.
b. Select a proper needle-guided bracket, and match the locating groove with the tab of the
probe. Mount the bracket onto the probe.
1 Block hole 2 V-shaped cover
3 Lock pin 4 Needle-shaped base
5 Needle-shaped scale 6 Angle adjusting block
7 Angle fixing nut 8 Groove
9 Pinch nut 10 Bracket clamp
11 V-shaped block
<11>
<1>
<2>
<3>
<4>
<5>
<6>
<7>
<10>
<9>
<8>
