Mindray Resona R9 Exp User Manual

17 Probes and Biopsy
Operator’s Manual 17 - 51
c. Tighten the pinch nut of the needle-guided bracket (following the arrow's direction) to
confirm that the needle-guided bracket is properly installed on the probe.
d. Adjust the dial scale to the required needle type shift.
e. Adjust the needle angle to the proper shift as required (loosen the nut first, and then
tighten the nut based on the shift you need).

Mindray Resona R9 Exp Specifications

General

Brand	Mindray
Model	Resona R9 Exp
Category	Diagnostic Equipment
Language	English
