Mindray Resona R9 Exp User Manual

17 - 64 Operator’s Manual
17 Probes and Biopsy
c. Tighten left/right clamp pinch nut to confirm that the needle-guided bracket is properly
installed on the probe.
d. Loosen left/right clamp pinch nut, and put it onto the guiding block fixing frame, then
tighten left/right clamp pinch nut.
e. Hold the probe, and insert the needle into guided hole.
2. Remove the needle-guided bracket:
a. Hold the probe and remove the needle.
b. Loosen left/right clamp pinch nut, and remove it from the guiding block fixing frame.
c. Loosen left/right clamp pinch nut, and remove the needle-guided bracket.
