9. Commissioning
MiR200 User Guide (en) 10/2020 - v.3.1 ©Copyright 2017-2020: Mobile Industrial Robots A/S. 107
CAUTION
The footprint is only used by the robot's global and local planner to avoid
obstacles. The Collision avoidance feature—see Collision avoidance on
page75—still uses the same field sets. If your robot is carrying a load or top
module that extends the footprint in front of or behind the robot, it may
collide with personnel or equipment.
• Avoid extending the footprint in front of or behind the robot.
• Mark all areas where the robot drives with an unsafe load as operating
hazard zones.
• Consider modifying the Protective field sets if necessary—see Collision
avoidance on page75.
For a more thorough guide to creating footprints, contact your distributor for
the guide How to change the robot footprint.
For more information about the footprint editor, see MiRRobot Reference
Guide on the MiR website.
If you want to change the footprint in a mission, use the Set footprint action found under the
Move action group. This is used to change the footprint when the robot picks up a load that
extends the footprint or places a load and the footprint returns to the default.
