462
12 DATA USED FOR POSITIONING CONTROL
12.5 Block Start Data
[Da.14] Parameter
Set the value as required for "[Da.13] Special start instruction".
[Da.13] Special start
instruction
Setting
value
Setting details
Block start (Normal start)  Not used. (There is no need to set.)
Condition start 1 to 10 Set the condition data No. (Data No. of "condition data" is set up for the condition judgment.) (Refer to
Page 463 Condition Data for details on the condition data.)
Wait start
Simultaneous start
Repeated start (FOR loop) 0 to 255 Set the number of repetitions.
Repeated start (FOR condition) 1 to 10 Set the condition data No. (Data No. of "condition data" is set up for the condition judgment.)
