(5) CH Digital output value (Un\G11 to Un\G14)
The A/D-converted digital output value is stored as a signed 16-bit binary.
(a) Updating cycle
When performing the average processing, the value is updated in each specified averaging processing cycle.
When the average processing is not performed, the value is updated in each sampling cycle.
(6) Latest error code (Un\G19)
Error codes or alarm codes detected in the A/D converter module are stored.
For details on error code and alarm code, refer to the following.
• Error code list ( Page 159, Section 11.4)
• Alarm code list ( Page 163, Section 11.5)
(a) Clearing an error
Turn OFF → ON → OFF Error clear request (YF).
(7) Setting range (Un\G20)
The setting content for input range can be checked.
Input range cannot be changed in Setting range (Un\G20).
For changing the setting, refer to the following.
● Switch setting ( Page 49, Section 7.2)
Input range Setting value
4 to 20mA
0
H
0 to 20mA
1
H
1 to 5V
2
H
0 to 5V
3
H
-10 to 10V
4
H
0 to 10V
5
H
4 to 20mA (Extended mode)
A
H
1 to 5V (Extended mode)
B
H
User range setting
F
H
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b0b1b2b3b4
Sign bit
1: Negative
2: Positive
Data section
b15 to b12 b11 to b8 b7 to b0tob3b4
CH1CH2CH3CH4
