APPENDICES
A
Appendix 2 Details of Buffer Memory Addresses
(8) Offset/gain setting mode Offset specification (Un\G22), Offset/gain setting
mode Gain specification (Un\G23)
Specify the channel to perform the offset/gain setting adjustment.
Offset/gain setting mode Offset specification (Un\G22): channel to adjust the offset
Offset/gain setting mode Gain specification (Un\G23): channel to adjust the gain
● The settings for multiple channels can be configured at the same time. However, set either of Offset/gain setting mode
Offset specification (Un\G22) or Offset/gain setting mode Gain specification (Un\G23) to be disabled (0).
When the settings for both of them are configured at the same time, a gain setting mode error (error code: 500) occurs.
● For details on offset/gain setting, refer to the following.
• Offset/gain setting ( Page 54, Section 7.5)
(9) Averaging process setting (Un\G24)
Configure the setting when selecting sampling or averaging processing for each channel.
Averaging processing includes time average, count average and moving average.
(a) Enabling the setting
Turn OFF → ON → OFF Operating condition setting request (Y9) to enable the setting.
(b) Default value
All channels are set to sampling (0) as the default value.
● When using Averaging process setting (used to replace Q64AD) (Un\G9), the value set in Averaging process setting
(Un\G24) is ignored. (The operation is performed in the averaging process setting in Averaging process setting (used to
replace Q64AD) (Un\G9).)
● The channel to which a value out of the above setting range is written performs the operation in the sampling processing.
Processing method Setting value
Sampling processing
0
H
Time average
1
H
Count average
2
H
Moving average
3
H
00000000000 CH1CH2CH3CH4 0
00000000000
CH1CH2CH3CH4 0
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b0b1b2b3b4
1: Setting-target channel
0: Invalid
Data for b4 to b15 are fixed to "0".
Offset/gain setting mode Offset specification (Un\G22)
Offset/gain setting mode Gain specification (Un\G23)
b15 to b12 b11 to b8 b7 to b0tob3b4
CH1CH2CH3CH4
