5 - 17 5 - 17
MELSEC-Q
5 UTILITY PACKAGE (GX Configurator-TC)
[Explanation of items]
(1) Command buttons
Make text file
Creates a file containing the screen data in the text file
format.
End setup
Saves the set data and ends the operation.
Cancel
Cancels the setting and ends the operation.
POINT
Initial settings are stored in the intelligent module parameters. After being written to
the CPU module, the initial setting is made effective by either (1) or (2).
(1) Cycle the RUN/STOP switch of the CPU module: STOP
RUN STOP
RUN.
(2) With the RUN/STOP switch set to RUN, turn off and then on the power or reset
the CPU module.
If the initialization settings have been written by a sequence program, the
initialization settings will be executed during the STOP
RUN of the CPU module.
Arrange so that the initial settings written by the sequence program are re-executed
during the STOP
RUN of the CPU module.
To Next Page
