MELSEC-Q
5 UTILITY PACKAGE (GX Configurator-TC)
5.5 Auto Refresh
[Purpose]
Configure the Q64HLC buffer memory for automatic refresh, for each channel.
For the automatic refresh setting types, refer to Section 5.1.
This auto refresh setting eliminates the need for reading and writing by sequence
programs.
[Operating procedure]
"Start I/O No. " "Module type" "Module model name" Auto refresh
Enter the start I/O No. in hexadecimal.
[Setting screen]
