MELSEC-Q
3 SPECIFICATIONS
3.5.11 Input range (buffer memory address 32, 64: Un\G32, Un\G64)
(1) Set the input range setting value according to the sensor and measuring range
used. The following table indicates the types and input range settings of input
sensor connected to the Q62HLC.
Input Input range Setting range
K -200 to 1372 0 (default value)
J -200 to 1200 1
T -200 to 400 2
S -50 to 1768 3
R -50 to 1768 4
N 0 to 1300 5
E -200 to 1000 6
B 0 to 1800 7
PL II 0 to 1390 8
Thermocouples
W5Re/
W26Re
0 to 2300
9
0 to 10mV 10
0 to 100mV 11
-10 to 10mV 12
Micro voltage
-100 to 100mV 13
0 to 1V 14
1 to 5V 15
0 to 5V 16
0 to 10V 17
-1 to 1V 18
-5 to 5V 19
Voltage
-10 to 10V 20
4 to 20mA 21
Current
0 to 20mA 22
(2) Be sure to set the input range in the setting mode (Yn1: OFF).
To determine the set value change, you must turn on the setting change
command (YnB).
(3) After the input range setting is changed, the measured value (PV) (buffer
memory address: 32, 64) turns to "0" for about 5 seconds and then the control is
resumed.
