2 SYSTEM CONFIGURATION
Applicable CPU module Base unit
*2
CPU type CPU model
No. of modules
*1
Main base unit Extension base unit
Q06CCPU-V
C Controller module
Q06CCPU-V-B
Up to 64
Applicable N/A
*1 Limited within the range of I/O points for the CPU module.
*2 Can be installed to any I/O slot of a base unit.
(b) Mounting to a MELSECNET/H remote I/O station
The table below shows the network modules and base units applicable to
the Q62HLC and quantities for each network module model.
Depending on the combination with other modules or the number of
mounted modules, power supply capacity may be insufficient.
Pay attention to the power supply capacity before mounting modules, and if
the power supply capacity is insufficient, change the combination of the
modules.
Base unit
*2
Applicable network
module
No. of modules
*1
Main base unit of
remote I/O station
Extension base unit of
remote I/O station
QJ72LP25-25
QJ72LP25G
QJ72LP25GE
QJ72BR15
Up to 64
Applicable
N/A
*1 Limited within the range of I/O points for the network module.
*2 Can be installed to any I/O slot of a base unit.
Remark
The Basic model QCPU or C Controller module cannot create the MELSECNET/H
remote I/O network.
(2) Support of the multiple CPU system
When using the Q62HLC in a multiple CPU system, refer to the following manual
first.
• QCPU User's Manual (Multiple CPU System)
(a) Intelligent function module parameters
Write intelligent function module parameters to only the control CPU of the
Q62HLC.
(3) Compatibility with online module change
Q62HLC is compatible with online module change.
2
