3 - 2 3 - 2
MELSEC-Q
3 SPECIFICATIONS
Table 3.1 Q62HLC performance specification list (from previous page)
Item Specifications
Control method Continuous proportional control
PID constant
setting
Auto tuning setting available
Proportional
band (P)
Thermocouple: 0.1 to Full-scale
Micro voltage, Voltage, Current: 0.1 to 1000.0%
Integral time (I) 0.0 to 3276.7s
PID constant
range
Derivative time
(D)
0.0 to 3276.7s
Set value setting range Thermocouple: Input range of the thermocouple to be used
Micro voltage, Voltage, Current: Set input range
Dead band setting range Thermocouple: 0.0 to 100.0
Micro voltage, Voltage, Current: 0.00 to 10.00%
Time accuracy 0.2%
Noise immunity
*2
Insulation part Insulation method
Dielectric withstand
voltage
Insulation resistance
Between input and
earth
Transformer
insulation
Between input
channels
Transformer
insulation
500VAC for 1 minute
500VDC 20M
or
more
Insulation
FeRAM read/write count Max. 10
10
times
Number of occupied I/O points 16 points/slot (I/O assignment: 16 intelligent points)
Connection terminal 18-point terminal block
Applicable wire size 0.3 to 0.75mm
2
Applicable crimping terminal R1.25-3, RAV1.25-3
24 VDC +20%, -15%
Ripple, spike 500mVP-P or less
Inrush current: 0.2A, 4ms or less
External power supply
0.07A
Internal current consumption 0.27A
Weight 0.25kg
External dimension 27.4 (W) 98(H) 112(D)mm
2: For the noise immunity, dielectric withstand voltage, insulation resistance and others of the programmable controller system which
uses this module, refer to the power supply module specifications given in the User's Manual of the CPU module used.
3
To Next Page
